1) Chrome Steel AISI52100
0.5mm-50.8mm Chrome Steel Ball G5/G10/G25/G50/G100/G1000
2) Size: 0.5mm-50.8mm
3) Grade: G5-G100
4) Hardness: HRC62-65
5) Certificate: ISO-9001,TS-16949, ISO14001
6) Feature: Good wearing, excellent surface quality and high hardness.
7) Application: Bearing, ball screw, linear motion guide, automotive parts, chemical, food processing, ink and paint grinding, caster wheel, slide rail bicycle and car.
OUR ADVANTAGES
1) Good preformance- 0 customer complain in the past 6 months
2) Strick quality control- ISO9001, TS16949, ISO14001
3) Advanced equipment- full set of quality inspection equipment, precision roller sorting machine(developped by ourselves), photo defectoscope
4) Puntual delivery
PERCIFICATIONS
Grade | Variation of Ball Diameter VDws |
Deviation from Spherical Form △Sph |
Variation of Ball Lot Diameter VDwl |
Surface roughness Ra |
G5 | 0.13 | 0.13 | 0.25 | 0.014 |
G10 | 0.25 | 0.25 | 0.5 | 0.02 |
G16 | 0.4 | 0.4 | 0.8 | 0.025 |
G20 | 0.5 | 0.5 | 1 | 0.032 |
G24 | 0.6 | 0.6 | 1.2 | 0.04 |
G28 | 0.7 | 0.7 | 1.4 | 0.05 |
G40 | 1 | 1 | 2 | 0.06 |
G60 | 1.5 | 1.5 | 3 | 0.08 |
G100 | 2.5 | 2.5 | 5 | 0.1 |
G200 | 5 | 5 | 10 | 0.15 |
G500 | 12.5 | 12.5 | 25 | |
G1000 | 25 | 25 | 50 |
