MODEL |
5 /10 TON ARL-005 |
10/15 TON ARL-010 |
30/45 TON ARL-030 |
|
CAPACITY ONE POWER AND ONE IDLER ROLL ONE POWER AND TWO or MORE IDLER ROLL |
5 TONS 10 TONS |
10 TONS 15 TONS |
30 TONS 45 TONS |
|
PU ROLLS DIAMETER FACE WIDTH |
400MM 100MM |
430MM 150MM |
500MM 200MM |
|
SPACE SPEED ( MM/MIN ) |
83MM~830MIN |
83MM~830MIN |
83MM~830MIN |
|
OVERALL DIMENSION POWER ROLL MACHINE LENGTH MACHINE WIDTH MACHINE HEIGHT OVERALL DIMENSION IDLER ROLL MACHINE LENGTH MACHINE WIDTH MACHINE HEIGHT |
2200MM 670MM 480MM 1850MM 330MM 480MM |
2600MM 770MM 500MM 3400MM 400MM 500MM |
3150MM 890MM 625MM 2900MM 500MM 625MM |
|
WORK PIECE MAX. DIAMETER MIN. DIAMETER |
2000MM 200MM |
3500MM 200MM |
4500MM 200MM |
|
APPROX. WEIGHT POWER ROLL IDLER ROLL |
380KG 200KG |
480KG 250KG |
950KG 450KG |
|
POWER SUPPLY |
AC 230 |
AC 230 |
AC 415 |
