MODEL |
AR-001 |
AR-003 |
AR-006 |
|
TURNING CAPACITY |
1000KG |
3000KG |
5000KG |
|
LOAD CAPACITY |
1000KG |
3000KG |
5000KG |
|
RUBBER ROLLS DIAMETER FACE WIDTH |
200MM 50MM |
200MM 50MM x 2 |
300MM 100MM |
|
MAX. SPEED ( MM/MIN ) |
1500MM/MIN |
1500MM/MIN |
1500MM/MIN |
|
OVERALL DIMENSION POWER ROLL MACHINE LENGTH MACHINE WIDTH MACHINE HEIGHT OVERALL DIMENSION IDLER ROLL MACHINE LENGTH MACHINE WIDTH MACHINE HEIGHT |
520MM 470MM 390MM 520MM 300MM 390MM |
800MM 370MM 360MM 800MM 260MM 360MM |
1900MM 470MM 390MM 1900MM 280MM 390MM |
|
WORK PIECE MAX. DIAMETER MIN. DIAMETER |
700MM 20MM |
1400MM 40MM |
4000MM 160MM |
|
APPROX. WEIGHT POWER ROLL IDLER ROLL |
45KG 20KG |
120KG 80KG |
169KG 141KG |
|
POWER SUPPLY |
AC 220 |
AC 220 |
AC 220 |
