SPECIFICATION
|
MODEL |
5/10 TONS |
10/15 TONS |
30/45 TONS |
40/60 TONS |
60/90 TONS |
90/130 TONS |
|
CAPACITY |
|
|
|
|
|
|
|
One Power and One Idler Roll |
5 Tons |
10 Tons |
30 Tons |
40 Tons |
60 Tons |
90 Tons |
|
One Power and Two or More Idler Roll |
10 Tons |
15 Tons |
45 Tons |
60 Tons |
90 Tons |
130 Tons |
|
RUBBER ROLLS |
|
|
|
|
|
|
|
Diameter (mm) |
400 |
430 |
500 |
500 |
220 |
550 |
|
Face Width (mm) |
100 |
150 |
200 |
250 |
200 x 2 |
200 x 3 |
|
SPACE SPEED |
|
|
|
|
|
|
|
MM/Min |
83-830 |
83-830 |
83-830 |
83-830 |
83-830 |
83-830 |
|
OVERALL DIMENSION |
|
|
|
|
|
|
|
Power Roll |
|
|
|
|
|
|
|
Length (mm) |
2200 |
2600 |
3150 |
3150 |
3312 |
3400 |
|
Width (mm) |
670 |
770 |
890 |
950 |
1230 |
1650 |
|
Height (mm) |
480 |
500 |
625 |
625 |
725 |
775 |
|
Idler Roll |
|
|
|
|
|
|
|
Length (mm) |
1850 |
3400 |
2900 |
2900 |
2900 |
2900 |
|
Width (mm) |
330 |
400 |
500 |
550 |
780 |
1050 |
|
Height (mm) |
480 |
500 |
625 |
625 |
725 |
775 |
|
WORK PIECE |
|
|
|
|
|
|
|
Max. Diameter (mm) |
2000 |
3500 |
4500 |
4500 |
4500 |
4500 |
|
Min. Diameter (mm) |
200 |
200 |
200 |
700 |
700 |
700 |
|
APPROX. WEIGHT |
|
|
|
|
|
|
|
Power Roll (Kg) |
380 |
480 |
950 |
1250 |
1650 |
2050 |
|
Idler Roll (Kg) |
200 |
250 |
450 |
550 |
950 |
1100 |
