It has a completely new architecture, significantly speeding up data processing speed, and can meet high-precision technical requirements.
Combined both 2D and 3D functionality.
Added high-performance motion control expansion capabilities, supports large-format processing control.
Connects via Ethernet, with unrestricted transmission distance, enabling remote control operations.
Supports various mainstream laser types.
onfigurations | |
Software Kernel | 64 Bit |
Laser | Supports CO2, YAG, FIBER, SPI, QCW, CW,etc., and can adjust current, pulse frequency, duty cycle, and other parameters based on different laser parameters through software. Can display the laser status in real-time, and JCZ laser digital communication protocol 1.0 supports almost all lasers available in the market. |
Red Light Display | Supports red light as an indicator |
Password Control | Supports password protection to prevent unauthorized parameter changes |
IO Control | Added port control functionality for easy automation of your machine |
Galvo Calibration | 3D calibration, traditional trapezoidal correction, barrel (pillow) correction, and parallelogram correction. Specialized calibration software to achieve extremely precise calibration results. |
Fill | Background fill, circular fill, arbitrary angle fill, cross fill, adjustable margins, borders, and spacing. Supports 8 layers of filling, with independent parameter settings for each layer |
Editing Functions | Multi-layer, 3D curve marking, slicing, dynamic filling, 3D curve projection, surface wrapping, bitmap to embossing, arbitrary curve text, arbitrary graphic drawing/editing, scatter/combine, group/ungroup, undo/redo, welding, trimming, cross, alignment, automatic curve connection, etc |
Text Input Function | Supports TrueType fonts, single-line fonts (JSF), dot matrix fonts (DMF), SHX, and supports user-created font libraries |
256 Layer Processing Parameters | Highly customizable for easy multi-parameter marking |
Barcodes and QR Codes | Code39, EAN, PDF417, DATAMATRIX, QR, PostNet, PL ANET, UK Royal Mail 4 state customer, AZTECCODE, MicroQRCODE, VERICODE etc |
Vector Files | PLT、DXF、Al、DST、SVG、GBR、NC、JPC、BOT |
Bitmap Files | BMP, JPG, JPEG, GIF, TGA, PNG, TIF, TIFF, Supports segmented processing |
Variable Text | Fixed text, date, time, keyboard input, skipping numbers, list files, dynamic files, supports Excel sheets, TXT files, serial communication, and network communication |
Multi-Language Support | Built-in Chinese, English, Korean, Japanese, French, German; can be easily localized by language packs for translation |
Optional Features | Four-axis point-to-point motion, Dual-axis splicing, flying marking, software secondary development |
Calibration Table | Supports loading and switching between up to 4 calibration tables simultaneously |
Multi-Layer XY Plane Calibration | Supports, greatly improving the XY plane calibration accuracy of 3D calibration |
Offline Mark | Supports switching and processing of up to 16 offline layers |
Online Circular Arc Interpolation Commands | Supports, for high-precision small circle processing |
Three-Dimensional Model Files | STL, DXF |
Processing Functions | Large-format dynamic focusing, projector positioning, multi-axis expansion, estimated processing time, ultra-fast point-like 2D barcode marking, uniform fill function, gradual power and speed control, circular and sine curve jitter, material parameter assistant function |
