Typical Application: Power line crossing water, Power line in industrial ,semi-industrial or coastal area, Airport fence, farm electrical fence, Vineyard wires and similar applications.
Aluminum clad steel wire advandge:
1:Superior corrosion resistance
2:Better conductivity
3: Flexibility for design because of wider range of combinations of tensile strength and conductivity.
4:Lighter weight
5: Excellent thermal stability : good as ACSS core
6:Wider variety of products: with broad range of properties, quality, and size of steel wire and aluminum cladding
Specification:
ASTM B 415 Hard Drawn Aluminum Clad Steel Wire
Nominal Dia. | Size | 20.3% | 27% | 30% | 40% | |||||
In/mm | AWG | Psi | Mpa | Psi | Mpa | Psi | Mpa | Psi | Mpa | |
0.2043 | 5.19 | 4 | 155000 | 1070 | 125000 | 862 | 102000 | 703 | 80000 | 552 |
0.1880 | 4.78 | 160000 | 1100 | 129000 | 889 | 106000 | 731 | 84000 | 579 | |
0.1819 | 4.62 | 5 | 165000 | 1140 | 133000 | 917 | 110000 | 758 | 88000 | 607 |
0.1729 | 4.39 | 170000 | 1170 | 137000 | 945 | 114000 | 786 | 92000 | 634 | |
0.1620 | 4.11 | 6 | 175000 | 1210 | 141000 | 972 | 114000 | 786 | 96000 | 662 |
0.1549 | 3.93 | 180000 | 1240 | 145000 | 1000 | 118000 | 814 | 96000 | 662 | |
0.1443 | 3.67 | 7 | 185000 | 1280 | 150000 | 1034 | 122000 | 841 | 98000 | 676 |
0.1369 | 3.48 | 190000 | 1310 | 154000 | 1062 | 126000 | 869 | 98000 | 676 | |
0.1285 | 3.26 | 8 | 195000 | 1340 | 156000 | 1076 | 128000 | 883 | 99500 | 686 |
0.1144 | 2.91 | 9 | 195000 | 1340 | 156000 | 1076 | 128000 | 883 | 99500 | 686 |
0.1019 | 2.59 | 10 | 195000 | 1340 | 156000 | 1076 | 128000 | 883 | 99500 | 686 |
0.0907 | 2.3 | 11 | 195000 | 1340 | 156000 | 1076 | 128000 | 883 | 99500 | 686 |
0.0808 | 2.05 | 12 | 195000 | 1340 | 156000 | 1076 | 128000 | 883 | 99500 | 686 |
