Purpose:
Hanging for engineering, plant hoist operations, civil hydropower pipe installation, storage access and other goods, use very extensive; and where Lifting / Ascension / drag and other operations are suitable, compact, light weight, easy to obtain single-phase power supply , effort and aging rate.
Features:
Motor system:
Efficient use of industrial-grade series excited brushless motor; there are two single-phase voltage (110V / 220V) Select Configure; enameled heat levels up to 200 degrees for a long time lifting specially designed.
Brake System:
Mechanical ratchet gear brake controller short-circuit resistance brakes, dual brake system; high friction coefficient formula oiled copper disc brakes, all without adjustment; power failure or malfunction immediately brake, safety marks, high life.
Electronic control system:
Direct control, save tedious line, easy maintenance, low failure rate, security and stability; control switch and power cord using separate quick connector, easy to carry, no wire entanglement trouble.
Chain Size:
imported from Japan by the FEC chain manufacturing giant manufacturing; 100 grade alloy steel, 3-fold safety factor.
Gear system:
Using the best efficiency of the transmission plus planetary reduction gear; planetary gear set using two steel heat treatment operation idler; power-sharing, the general life of more than 2 times the transmission type.
Infrastructure:
4.5MM support the use of high-strength steel crane architecture; using electrodeposition paint, rust resistance, suitable for harsh environments -15 degrees to + 65 degrees.
Housing parts:
Motor body is one piece aluminum die-casting, strong toughness, computer CNC machining, high precision, rotor running smoothly, low noise; gear box of aluminum alloy casting body shape, strong toughness, computer CNC machining; completely sealed IP waterproof coefficient 65; use automotive-grade powder coating, appearance.
Upper and lower hook Group:
Alloy steel hot forging molding, high strength safety factor of 4 times.
|
Model |
Capacity |
Power |
Phase |
Lifting Hight |
Chain |
Speed |
Motor |
Load Chain |
||
|
LHUS-901 |
500 |
100-120 |
200-240 |
1 |
3 |
1 |
5 |
6 |
1.3 |
6.3 |
|
LHUS-902 |
1000 |
100-120 |
200-240 |
1 |
3 |
2 |
2.5 |
3 |
1.3 |
6.3 |
|
Model |
L |
W |
H |
Package Box (mm) L W H |
Cu.Ft |
N.W |
G.W |
||
|
LHUS-901 |
450 |
210 |
480 |
500 |
300 |
400 |
2.1' |
19 |
23 |
|
LHUS-902 |
450 |
210 |
500 |
500 |
300 |
400 |
2.1' |
23 |
27 |
