FX-120I | FX-200I | FX-300I | FX-500I | FX-1200I | FX-2000I | FX-3000I | FX-5000I | ||
Capacity x Resolution |
g | 122 x 0.001 | 220 x 0.001 | 320 x 0.001 | 520 x 0.001 | 1220 x 0.01 | 2200 x 0.01 | 3200 x 0.01 | 5200 x 0.01 |
oz | 4.30 x 0.00005 | 7.76 x 0.00005 | 11.28 x 0.00005 | 18.34 x 0.00005 | 43.0 x 0.0005 | 77.6 x 0.0005 | 112.8 x 0.0005 | 183.4 x 0.0005 | |
lb | 0.268 x 0.000005 | 0.485 x 0.000005 | 0.705 x 0.000005 | 1.14 x 0.000005 | 2.68 x 0.00005 | 4.85 x 0.00005 | 7.05 x 0.00005 | 11.46 x 0.0005 | |
lb-oz | 0lb, 4.30oz x 0.01oz | 0lb, 7.76oz x 0.01oz | 0lb, 11.29oz x 0.01oz | 0lb, 18.34oz x 1lb, 0.01oz |
2lb, 11.03oz x 0.01oz | 4lb, 13.60oz x 0.01oz | 7lb, 0.88oz x 0.01oz | 11lb, 7.65 x 1lb, 0.001oz |
|
ozt | 3.92 x 0.00005 | 7.07 x 0.00005 | 10.28 x 0.00005 | 16.71 x 0.00005 | 39.2 x 0.0005 | 70.7 x 0.0005 | 102.8 x 0.0005 | 167.18 x 0.005 | |
ct | 610 x 0.005 | 1100 x 0.005 | 1600 x 0.005 | 2600 x 0.005 | 6100 x 0.05 | 11000 x 0.05 | 16000 x 0.05 | 26000 x 0.05 | |
dwt | 78.6 x 0.001 | 141.7 x 0.001 | 206.2 x 0.001 | 335.1 x 0.001 | 786 x 0.01 | 1417 x 0.01 | 2062 x 0.01 | 3351 x 0.01 | |
GN | 1882 x 0.02 | 3395 x 0.02 | 4938 x 0.02 | 8024 x 0.02 | 18827 x 0.2 | 33951 x 0.2 | 49383 x 0.2 | 80248 x 0.2 | |
Counting Mode | Min. Unit Mass |
0.001g | 0.01g | ||||||
# of Samples |
5, 10, 25, 50 or 100 pieces | ||||||||
Percent Mode | Min. 100% Ref. Mass |
0.100g | 1.00g | ||||||
Min. 100% Display |
0.01%, 0.1%, 1% (depends on the reference mass stored) | ||||||||
Repeatability (Std. Deviation) |
0.001g | 0.01g | |||||||
Linearity | ±0.002g | ±0.02g | |||||||
Stabilization Time (typically set at FAST) |
Approx. 1 second | ||||||||
Sensitivity Drift (10°C to 30°C) |
±2ppm / °C | ||||||||
Operating Temp | 5°C to 40°C (41°F to 104°F), 85% RH or less (No condensation) | ||||||||
Display Type | Vacuum Fluorescent Display (VFD) | ||||||||
Display Refresh Rate | 5 times / second, 10 times / second or 20 times / second | ||||||||
Std. Serial Interface | RS-232C Interface | ||||||||
Weighing Pan | 130mm | 150mm | |||||||
External Calibration | 100g 50g |
200g 100g |
300g 200g 100g |
500g 400g 300g 200g 100g 50g |
1000g 500g |
2000g 1000g |
3000g 2000g 1000g |
5000g 4000g 3000g 2000g 1000g 500g |
|
AC Adaptor | Confirm that the adaptor type is correct for the local voltage and power receptacle | ||||||||
Power Consumption | Approx. 11VA (supplied to the AC Adaptor) | ||||||||
External Dimensions | 193 (W) x 262.5 (D) x 84.5 (H) mm | ||||||||
Net Weight | Approx. 2.5kg |
