Flange Clamp, Lifting Hook, Stacking Plate Formwork Accessories



单价 面议对比
询价 暂无
浏览 76
发货 AsiaChina
过期 长期有效
更新 2013-10-09 10:00

联系方式
加关注0

CCCC FWK INTERNAITONAL FORMWORK CORPORATION

VIP   Company第8年
资料未认证
保证金未缴纳
  • Asia-China
  • 上次登录 2013-10-09
  • Angela (女士)
详细说明

Detailed Product Description






Flange Clamp

Timber Beam Bracket


Water Stop Connector


Flange Clamp, Lifting Hook, Stacking Plate Formwork Accessories


Description:

1. Brief introduction
CON accessories are specially used in different formwork system.






2. Series and specification


No.

Name & Sketch

Weight(Kg)

Spec. & tech. parameter

Remarks



09000081

09000082

09000083

Flange Clamp



0.74

0.88

0.9

For steel waling

[10~[12

[14

[16

For connecting
timber beam

to steel waling.

09000084

Lifting Hook

4.65

H20

For lifting
the formwork.

09000085

Stacking Plate

4.84

H20

For connecting
 the beams.



09000086

Timber Beam Bracket

13.58



Install on
the beam.



09000121

09000131

09000134

09000141

Formwork Element Connector



7.38

8.5

7.3

13.52



[10

[12

[12 L=820

[14

For connecting

 waling, length

 as required.



09000122

09000132

09000142

Shaft Waling Squaring Connector



8.44

10.64

16.08



[10

[12

[14

For connecting
waling, length
 as required.



09000123

09000133

09000143

Adjustable Shaft
Waling Squaring  Connector



9.16

9.48

12.82



[10

[12

[14

For connecting
waling, length
as required.



09000151

0900152



Water Stop Connector



0.62

0.80



D15

D20



For wall-through
 tie-rod.



09000161

09000162

Tie-Yoke



2.30

2.20



[12~[16

[10



For connecting

 upright formwork.

09000163

Beam Clamp I

1.44

[10

For connecting
element connector.

09000164

Beam Clamp II

1.47

[12

For connecting
element connector.

09000165

Beam Clamp III

1.09

[14~[16

For connecting
 element connector.

09000166

Wedge

0.59



For connecting steel
waling and
element connector.



09000167

09000168

Gib Head Bolt



0.18

0.31



L=145

L=253

For connecting wood
batten and steel waling.



09000171

09000172

09000173

Column Hoop



12.01

21.76

16.28



[10 L=1200

[12L=1600

[12 L=1200

[10 For the cube

with the cross section

less than 80x80cm;

[12 For the cube

with the section less

than 120x120cm.



09000221

09000224

PVC Pipe Plug



0.008

0.008



Φ21.5

Φ27.5





09000222

09000225

PVC Joint



0.004

0.004



Φ26/Φ22

Φ31/Φ28



09000223

PVC Pipe Plug

0.004

Φ26

Other size can also
 be supplied as required.

09000233

Waling Bracket

14.02



Install on the
 steel waling.

09000241





09000242

Tie Rod



1.06

1.94

D20/L=300

Max. load:270kN

Allowable load:140kN

D26.5/L=350

Max. load:400kN

Allowable load:200kN

Other length can be
 supplied as required,
the largest length is 12m,
 galvanized as required.



09000052

09000062

Wing Nut



0.35

0.62



D20

D15







For tie-rod D20,

galvanized;

For tie-rod D15,
galvanized.



09000053

09000063

Hexagon Nut



0.18

0.56



D15

D20





For tie-rod D15,
galvanized;

For tie-rod D20,
galvanized;



09000054

09000064

Tri-Wings Nut



0.87

0.89



D15

D20







For tie-rod D15,
galvanized;

For tie-rod D20,
galvanized;



09000055

09000065

Flange Nut



0.63

0.65



D15

D20



For D15 tie-rod,galvanized;

For D20 tie-rod,galvanized.



09000056

09000066

Flange Nut



0.88

0.90



D15

D20

For D15 tie-rod,
galvanized;

For D20 tie-rod,
galvanized.

09000057

Super PlateNut

1.39

D15

For the situation that
tie-rods and the panels
are not vertical.

09000058

Two-Wings Nut

0.70

D15



For D15 tie-rod,
galvanized.



09000011

09000021

09000012

09000022

09000013

09000024

Steel Waling





10.85

17.44

14.47

34.88

28.94

66.54



[12  L=900

[14  L=1200

[12  L=1200

[14  L=2400

[12  L=2400

[14  L=4800



09000014

Right Steel Waling

30.02

[12



09000015

Reversed Steel Waling

30.02

[12



09000025

Steel Waling

(the length is various)



















[14





09000031

09000041

09000032

09000042

09000033

09000043

09000034

09000044

09000045

Tie Rod







1.78

2.98

2.14

4.47

2.67

8.95

3.38

13.42

17.6



D15 L=1000

D20 L=1000

D15 L=1200

D20 L=1500

D15 L=1500

D20 L=3000

D15 L=1900

D20 L=4500

D20 L=5900

D20 Max. load:270kN

Allowable load:140kN;

D15Max. load:160kN

Allowable load: 85kN.

Other length can be
supplied as required.



09000071

09000072

09000073

Cast Washer Plate I



0.37

0.74

1.32



60X120

100x100

120x120

For tie-rod D15

For tie-rod D15

For tie-rod D20

09000074

Punch Washer Plate

0.68

120x120

For tie-rod D20



Applications

As a professional formwork engineering company,FWK has accumulated abundant experience in formwork systems in different concrete building field. As part of formwork system, accessories played a very important role. Over the years research and development, CNBM has owned mature accessories products series, which will be applying in different formwork systems.
