Xenon Arc Tester/features:
1. Advanced design technology and concept,
2. Excellent technology of producing and outstanding system of quality management,
3. Xenon lamp tester can be the most realistic simulated solar spectrum, including ultraviolet,
visible and infrared.
4. Be tested in the range of the full spectrum, necessary for most textile sun and color fastness test.
5. To determine the color fastness and aging to sunlight, weather resistance, etc.
xenon arc testing machine/technical parameters:
1. Model: XL-1000
2. Internal Dimension WxHxD (mm): 900x900x900
3. External Dimension WxHxD (mm): 1500x2000x1400
4. Tube Using Life (H): 1500
5. Tube Power: 1KW/6KW
6. Illumination Intensity: 340nm 0.35~0.6w/m2;
7. BPT 40~120℃(±3℃)
8. BST 38~120℃(±3℃)
9. Humidity Control Range of the Test Cabinet:
Humidity when lighting: 20%R.H. ~75%R.H. (± 5%R.H.)
Humidity when dark: 60%R.H. ~95%R.H. (± 5%R.H.)
10. Rotating Speed of the Samples Holder (RPM): 1~5 adjustable
11. Diameter of Sample Shelf mm): 500±50
12. Sunlight Exposure Cycle: 0.01~999 hours 59mins
13. Raining Period/ Time:
Raining Period: 1~240mins, discontinuous-type, adjustable
Raining Time: 1~9999mins, adjustable, water spray pressure 70~130Kpa
14. Spray water flow (L/min): 1~2.4
15. Explore Area (cm2): 7500
16. Power: AC 380 V(±10%),50/60HZ ,3∮ 5 Lines
