Standard Features of 400kva/320kw Cummins diesel generator
1) Four stroke water cooled Cummins diesel engine
2) Alternator: Leroy Somer/ Stamford/Marathon (brushless and self-exciting)
3) Power Range: 20-1320KW
4) Output mode: Three phase four wire; Output Voltage: 380/220V, 400/230V, 415/240V, 440V, 480V, 127V
5) Frenquency: 50HZ/60HZ; Power factor: 0.8;
6) Steady State Voltage regulation: ± 1%; Insulation class: H; Protection: IP23
7) Global Warranty
Details
| Diesel Genset | |
| Prime Power | 320kw/400kva |
| Standby Power | 352kw/440kva |
| Rated speed | 1500/1800rpm |
| Frequency | 50/60hz |
| Voltage | 230/400V |
| Phase and wire | 3 phase and 4 wires |
| Fuel consumption | 206g/lwh |
| Dimension | 3100*1400*1600mm |
| Weight | 3000kg (just for reference) |
| Engine | |
| Brand | Cummins NTAA855-G7A |
| Cooling | Water cooling |
| Cylinders | 6 |
| Stroke | 4 |
| Governing system | Electrical |
| Bore(mm)*Stroke (mm) | 140*152 |
| Alternator | |
| Brand | Stamford (HCI444F) |
| Characteristics | Brushless, self-excitation |
| Protection class | IP23 |
| Insulation | H |
| Power Factor | 0.8 |
