Operation Modes
|
PC Connection |
Cutter
|
Auto |
Cutter Life
|
Up to 300,000 (die-cut labels) 150,000 (continuous labels) |
Maximum Print speed (labels per min.)
|
Up to 93 standard address labels per min |
Maximum Print Speed (mm per min)
|
150mm per sec |
Display
|
1-Colour LED |
Tape Sizes
|
Up to 62mm |
Maximum tape width (inches)
|
2.4 (62mm) |
Maximum print width (inches)
|
2.3 (59mm) |
Maximum label length
|
3 feet (1000mm) |
Maximum Resolution (dpi)
|
300 x 600 (Superfine mode) |
Font Styles
|
True Type |
Symbols for windows ( No. of Clip arts in P-touch Editor)
|
1379 |
Multiple Copies
|
Up to 9999 copies |
Mirror Printing
|
Yes |
Vertical Printing
|
Yes |
Rotate Printing
|
Yes |
Date/Time Stamp
|
PC Generated |
Bar-codes types
|
Code 39, 1-2/5, UPC-A, UPC-E, EAN 13, EAN 8, CODABAR (NW-7), CODE 128, EAN 128, POSTNET, Laser Bar Code, ISBN-2, ISBN-5, PDF417, QR CODE, Data Matrix, UCC/EAN-128(GS1-128), ITF(I-2/5), EAN13(JAN13), GS1 DataBar(RSS), GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded, GS1 DataBar Expanded Stacked, PDF417(Standard, Truncate, Micro), QR Code(Model 1, Model 2, Micro), Data Matrix (ECC200 Square, ECC200 Rectangular), MaxiCode |
Microsoft Word Add-in
|
Yes |
Microsoft Outlook Add-in
|
Yes |
Microsoft Excel Add-in
|
Yes |
Database file compatibility
|
csv, txt, mdb, xls, Microsoft SQL Server Database |
Software
|
P-touch Editor for Windows / Mac |
Interface
|
USB |
Compatibility
|
PC & Mac OS® |
Operating System
|
Windows® XP, Windows Vista®, Mac OS X 10.1-10.5, Mac: 10.3.9-10.4.10 |
Carton Contents
|
P-touch® Software & Driver, USB Cord, Quick Set-up Guide, Power Cord, Starter Rolls: DK-2205 2-3/7" (26.7 feet) continuous length, DK-1201 Standard address label (100 labels) |
