SIMPLEX-MS - Sanitary simplified centrifugal pump
Patented:
Utility Model No 9101925
Utility Model No 286465 |
| Flow rate |
Q = 1 to 30 m3/h |
| Total head |
H = 5 to 35 mwc |
| Motors |
P = 0.5 to 4 hp
(0.37 to 3 kW) |
| Temperature |
T = 80ºC
(Special seal 120ºC) |
| Material |
AISI-316L |
| Aplications |
Water, wine, brine and juices etc. |
|
STAMP-STN/S - Cold pressed sanitary centrifugal pump
| Flow rate |
Q = 1 to 45 m3/h |
| Total head |
H = 5 to 40 mwc |
| Motors |
P = 0.5 to 5.5 hp
(0.37 to 4 kW) |
| Temperature |
T = 80ºC
(special seal 120ºC) |
| Material |
AISI-316L |
| Aplications |
Water, wine, alcohol and juices etc. |
|
|
SANIX-01 - Sanitary centrifugal pump
Patented:
Utility Model No 286465 |
| Flow rate |
Q = 1 to 150 m3/h |
| Total head |
H = 5 to 100 mwc |
| Motors |
P = 0.5 to 30 hp
(0.37 to 22 kW) |
| Temperature |
T = 100ºC
(special seal 130ºC) |
| Material |
AISI-316L |
| Aplications |
Milk, beer, wine, water, juices, syrups and whey etc. |
|
LACTIC - Hygienic centrifugal pump
| Flow rate |
Q = 1 to 120 m3/h |
| Total head |
H = 5 to 85 mca |
| Motors |
P = 0.5 to 30 hp
(0.37 to 22 kW) |
| Maximum viscosity |
V = 300 cP |
| Temperature |
T = 180ºC |
| Material |
AISI-316 |
| Aplications |
Dairy, pharmaceutical, food industry etc. |
|
