stainless steel continuous slot screen



单价 RM500.00 / meter对比
销量 暂无
浏览 104
发货 AsiaChina预售,付款后10天内
库存 50meter起订20meter
品牌 GUANGXING
型号 GX8536
规格 ISO9001:2000
过期 长期有效
更新 2012-09-20 11:02

联系方式
加关注0

HENGSHUI GUANGXING WEDGE WIRE CO.,LTD

VIP   Company第8年
资料未认证
保证金未缴纳
  • Asia-China
  • 上次登录 2012-12-30
  • Alice Li (先生)   Sales Manager
详细说明


The Continuous slot screen is manufactured by wrapping a profile wire cylindrical around longitudinal placed support rods creating a V shaped non clogging slot opening.
Depending on the type of wire used and the slot opening, the open area of a wedge wire screen can vary between 10% and 70% of the total area.

The average opening area of a water well screen varies from 35% to 45% compared with 5% to 15% on average of a other screens (e.g. perforated or bridge screen).
In the case of support grids, the filtering area can be up to a 70% of total area, depending on the material used and the slot.

The continuos slot water screen has several advantages compared to other screens such as bridge slot screen or perforated screen.
A larger opening (filtering) area of a wedge wire screen leads to superior performance of a water well compared against the installation of other types of screens.
Moreover a wedgewire filter for water well are self-cleaning (go no go), thus, prevents losses due to friction as well as losses associated with pumping sand.
Also, a continuous slot wedgewire water well screen eliminate the problems associated with fine sands, thus, increasing the life of the pumping equipment.

NB  1.5", 2", 3", 4", 6", 8", 10", 12", 14",16"
 Slot     (mm)  0.15,0.25, 0.50, 0.75,1.00,1.50,2.00,3.00
 Lengths  6 Mts. & 3 Mts.
 Grades  Different grades suitable for tube well depths up to 300 ft., 600 ft., 900 ft. and 1500 ft.
 Material  Low Carbon Galvanized Steel ( LCG ) and  Stainless Steel ( SS-304 )
 End Connection  Plain beveled ends for butt welding or threaded.
