HIGH PRECISION PLANETARY SERVOBOX
DB Series
are available in compact design and universal housing with precision bearings planetary gearing provides high torque density while offering high positioning performance.
LDS High Precesion Planetary Servo Gear Reducers are available in compact design and universal housing with precision bearings planetary gearing provides high torque density while offering high positioning performance.
Product Specification Summary:
Model: #44 ▪ #62 ▪ #90 ▪ #120 ▪ #142 ▪ #180 ▪ #220
Max Output Torque: (3 times of rated output torque)
Low Backlash:
DB Series: 1 - 12 arcmin (please specify)
DB Series: 1 - 12 arcmin (please specify)
DB -A Series: 3 - 14 arcmin (please specify)
High Efficiency: ≥ 97%/ 94%
Gear Reduction Ratio (1/X): 3 ▪ 4 ▪ 5 ▪ 6 ▪ 7 ▪ 8 ▪ 9 ▪ 10 ▪ 12 ▪ 14 ▪ 15 ▪ 16 ▪ 18 ▪ 20
25 ▪ 30 ▪ 35 ▪ 40 ▪ 50 ▪ 60 ▪ 70 ▪ 80 ▪ 90 ▪ 100 ▪ 120 ▪ 140 ▪ 160 ▪ 180 ▪ 200
Drive Unit (Input Option): Compatible with any servo motor brand (universal mounting)
▪ Low Noise Level
▪ IP65 Gearbox Protection
▪ Fast delivery lead-time within 2 weeks* for non-exstock item
