- Compact, lightweight and portable
- Single - dial adjustable welding current allowing infinite current control
- Adopting variable regulating
- Stable arc, easy control, pool's depth, beautiful welding seam
- Automatic protective function of over - voltage & current
Specification
| Input Power Voltage (V) | 220V ± 15% |
| Frequency (Hz) | 50/60 |
| Rated input power capacity (KVA) | 7 |
| No-Load Voltage (V) | 56/9 (V.R.D) |
| Output current adjustment range (A) | 20 - 200 |
| Output voltage (V) | 28 |
| Duty Cycle(%) (25 °C) | 60 |
| No-Load Consumption (W) | 40 |
| Power factor (COS ᶲ) | 0.93 |
| Effiency (%) | 85 |
| Measurement (mm) | 425 x 205 x 355 |
| Weight (KG) | 12 |
| ARC force adjustment (A) | 0 - 60 |
| Diameter of rod (mm) | 2.0 - 3.2 |
