Parameter Unit Value (Data)
Range Kg 0.5,1,2,3,5,10,20,30,50,100
Range Kg 0.5,1,2,3,5,10,20,30,50,100
Output Sensitivity mV / V 1.0 ± 0.15
Comprehensive error % F.S 0.05/0.03
Temp.effect On Zero % F.S(30min) 0.05/0.03
Zero temperature drift % F.S/10°c 0.05/0.03
Temp.effect On Zero % F.S(30min) 0.05/0.03
Zero temperature drift % F.S/10°c 0.05/0.03
Zero Output mV / V ± 0.1
Input Resistance Ω 1055±15
Output Resistance Ω 1000±5
Overload Capacity % F.S 200
Overload Capacity % F.S 200
Recommended excitation voltage (Recommend excitation) 0.5-10V.
The maximum excitation voltage (Maximum excitation) 15V.
RED: E+ BLACK: E- WHITE: V- BLUE or GREEN: V+
