Features:
- Ultra wideband radar sensor system for detection accurate to the millimetre of ferrous/non-ferrous metals, electrical cables, wooden beams and plastic pipes such as floor and wall heating pipes
- Precise detection of rebar in concrete up to 15 cm deep
- Digital display of material properties and maximum permitted drilling depth
- Four different types of sensors for maximum safety. Detection of all materialsMetal, Wood, AC, Plastic
- Material classification and digital drilling depth indication for highest safety
- Calibration free - ready anytime
- Small & ergonomic design
- Maximum detection depth of 15cm
- Large, illuminated display - Easy to read and interpret
- Intuitive user interface in 7 languages with self-explanatory detection modes
- Robust: protected against dust and water (IP 54). Drop tested up to 1m. For reliable usage on every jobsite
Modes:
| Mode | Detects | Does not detect | Max. detection depth |
| Universal mode (Default) |
Metal, AC, plastic pipes, cavities |
Wood, cavities, empty plastic pipes < 20mm diameter |
60mm |
| Concrete deep | Metal, AC, plastic pipes, cavities |
Wood, cavities, empty plastic pipes < 20mm diameter |
150mm |
| Panel heating | Filled metal- and plastic pipes, AC, cavities |
Empty plastic pipes | 80mm |
| Dry wall | Wood, Metal, AC, filled plastic pipes, cavities |
Empty plastic pipes | 60mm |
| Hollow block | Metal, AC, plastic pipes |
Cavities, empty plastic pipes < 20mm diameter | 60mm |
Comes with:
- 4 batteries
- Protective case
Product Specification
- Maximum measuring depth 15cm
- Accuracy of object center (a) ± 0.5cm
- Accuracy of indicated drilling depth (b) ± 0.5cm
- Minimum distance between two objects (c) 4cm
- Detectable materials Metal, AC, Wood, Plastic
- IP class IP 54
- Working hours (batteries) 5h
- Working hours (rechargable batteries: 2500 mAh) 7h
- No. of measurements (batteries)* ~1,000
- No. of measurements (rechargable batteries)* ~1,500
- Weight 0.7kg
- Dimensions 220 × 97 × 120 mm
- Total Shipping Weight: 3kg
*approx. 15-20sec per measurement
