- Strong and robust motor for longer lifetime
- Higher power for faster work progress
- Good dust insulation
- Ventilation holes specially designed for dust insulation and optimal air circulation
- Flat bearing flange with channel design to prevent dust accumulation
- Ergonomic handle with dimples and soft grip for anti-slip and extra handling comfort
- Optimized gripping space for extra comfort
- Clear view of cutting line at 45° and 90°
- Compact and adjustable base plate for 45° bevel cut
Part no. 0 601 36A 2L0
- Clamping bolt with washer (1 619 P00 278)
- Clamping flange (1 619 P06 295)
- Mounting flange (1 619 P07 057)
- Allen key KW 5 (SP no. 1 907 950 006)
- Ring spanner (SP no. 1 619 P00 281)
Technical data
| Rated power input | 1300 W |
| No-load speed | 12000 rpm |
| Weight without cable | 2,8 kg |
| Saw blade bore | 20,0 mm |
| Saw blade diameter | 110 mm |
| Cutting depth | |
| Cutting depth (90°) | 34 mm |
| Cutting depth (45°) | 22 mm |
