- Ball grommet for preventing cable breaks
- Softgrip on main handle and auxiliary handle for a secure hold
Part no. 0 611 254 76A
Auxiliary handle (2 602 025 141)Carrying case (2 605 438 098)
Depth stop 210 mm (1 613 001 010)
Keyless chuck 13 mm (2 608 572 212)
Pointed chisel (SP no. 2 608 690 095)
SDS-plus quick-change chuck (2 608 572 213)
Set of concrete drill bits (6.5, 8, 10 mm)
Technical data
| Rated power input | 800 W |
| Impact energy | 0 - 3 J |
| Impact rate at rated speed | 0 - 4000 bpm |
| Rated speed | 0 - 900 rpm |
| Weight without cable | 2,9 kg |
| Length | 407 mm |
| Width | 83 mm |
| Height | 210 mm |
| Toolholder | SDS-plus |
| Drilling range | |
| Drilling dia. concrete, hammer drill bits | 4 - 26 mm |
| Opt. appl. range concrete, hammer drill bits | 8 - 16 mm |
| Max. drilling dia. masonry, core cutters | 68 mm |
| Max. drilling dia. steel | 13 mm |
| Max. drilling dia. wood | 30 mm |
Functions
- Infinitely variable speed control
- Forward/reverse operation
- Electronic
- Overload clutch
