•3-phase 3-line DC-to-AC Solid State Relay
•Rated Load Current: 10A, 25A, 40A, 50A, 75A, 100A
•Input Current: 6_10mA
•Input Control Range: 6_32VDC
•4KV Insulation Strength
•Zero-crossing Trigger
•Equipped with Snubber Circuit.
•Operating Voltage: 24_280VAC / 48_480VAC
•Dimension: 103.5(L) x 78.0(W) x 38.0(H) mm
1) Adopting optically coupled isolators, insulation strength of input-output can reach 4KV.
2) Adopting zero-cross trigger to prevent EMI or EFI.
3) Provided with snubber circuit to absorb surges.
4) High over-current resistance, applicable to lamp or motor load switching.
5) High reliability and long service life
