DOW FILMTEC BW30-4040

Detailed Product Description

1.Salt Rejection : 99.5%
2.Operate pressure : 225psi
3.Permeate : 2400 GPD
4.4040 RO membrane

DOW FILMTEC BW30-4040

Origin : MADE IN USA

FILMTECTM reverse osmosis (RO) membrane elements for home drinking water are the industry’s most reliable. Advanced membrane technology and automated fabrication allow these elements to deliver consistent performance that equipment suppliers, water treatment dealers and residential customers can rely on. FILMTEC elements are shipped dry for convenient handling and long shelf-life. These elements are NSF/ANSI Standard 58 listed.

Equipment suppliers can take advantage of FILMTEC’s Standard 58 listing and participation in the NSF Data Transfer Protocol to reduce costs for reduction claims for their systems. FILMTEC home drinking water elements are rated a 50 PSI and will purify about 20% more water than competitive elements rated at 60 PSI (please see reference charts on page two for more information).


TAP WATER MEMBRANE

Product Code	Permeate GPD	Salt Rejection (%)	Size (Inch)
TW30-2521	325	99.5	2.5 X 21
TW30-2540	850	99.5	2.5 X 40
TW30-4021	900	99.5	4.0 X 21
TW30-4040	2400	99.5	4.0 X 40

BRACKISH MEMBRANE

Product Code	Permeate GPD	Salt Rejection (%)	Size (Inch)
BW30-2540	850	99.5	2.5 X 40
BW30-4040	2400	99.5	4.0 X 50
BW30-400	10500	99.5	8.0 X 40
BW30-400i	11500	99.5	8.0 X 40

1. Permeate flow and salt rejection based on the following test conditions: 250 PPM softened tap water, 77 Fahrenheit (25 degree C), 15% recovery and the specified applied pressure.

2. Minimum salt rejection is 96.0%.

3. Permeate flows for individual elements may vary +/-20%.

OPERATING LIMITS:

• Membrane Type: Polyamide Thin-Film Composite
• Maximum Operating Temperature: 113 Fahrenheit (45 degree C)
• Maximum Operating Pressure: 300 PSIG (21 bar)
• Maximum Feed Flow Rate: 2.0 GPM (7.6 LPM)
• H Range, Continuous Operation: 2 – 11
• pH Range, Short-Term Cleaning (30 min.): 1 – 12
• Maximum Feed Silt Density Index (SDI) : 5
• Free Chlorine Tolerance: < 0.1 PPM
  * Maximum temperature for continuous operation above pH 10 is 95°F (35°C).
  * Refer to Cleaning Guidelines in specification sheet 609-23010.
  * Under certain conditions, the presence of free chlorine and other oxidizing agents will cause premature membrane failure. Since oxidation damage is not covered under warranty, FILMTEC recommends removing residual free chlorine by pretreatment prior to membrane exposure. Please refer to technical bulletin 609-22010 for more information.

GENERAL INFORMATION:

• The first full tank of permeate should be discarded. Do not use this initial permeate for drinking water or food preparation.
• Keep elements moist at all times after initial wetting.
• If operating limits and guidelines given in this bulletin are not strictly followed, the limited warranty will be null and void.
• To prevent biological growth during prolonged system shutdowns, it is recommended that membrane elements be immersed in a preservative solution.
• The membrane shows some resistance to short-term attack by chlorine (hypochlorite). Continuous exposure, however, may damage the membrane and should be avoided.
• The customer is fully responsible for the effects of incompatible chemicals and lubricants on elements. Their use will void the element limited warranty.

FEATURES AND BENEFITS:
FILMTEC Drinking Water Elements use Automated Manufacturing

• The industry's most consistent and reliable product

FILMTEC Drinking Water Elements Contain FILMTEC Membrane

• Provides proven world leadership in reverse osmosis technology
• Provides consistent high quality water
