APPLICATION
Outdoor or Indoor
For use with shingle wire armoured 'W',wire braided 'X', steel tape armoured 'Z' and non-armoured (A2) elastomer and plastic insulated cable.
When using this type of gland with non armoured cable the armour clamping components are still required for compression of inner seals.
FUNCTION
- Provides armour clamping, using one component for armour / braid types W, X, Z.
- Provides a seal on inner sheath of cable.
- Provides a seal on outer sheath of cable.
501 / 453 / RAC CERTIFICATION AND APPROVAL
BASEEFA Certificate No: Ex 94C1336U.
EExd and EExe. EN 50014, EN 50018 and EN 50019.
Suitable for use in Zone 1 and Zone 2.
Suitable for Group IIA, IIB, IIC.
Meets the requirements of IP 66
OPERATING TEMPERATURE RANGE
-60°C to +100°C
MATERIALS AND FINISHES
Hawke glands are manufactured as standard in brass. Alternative materials and plating are available upon request.
CORROSION RESISTANCE
All brass components are treated with a special finish to withstand harsh environmental conditions.
VARIATIONS
Alternative certified entry thread types Pg, BSPP, BSPT, ET and NPSM are available.
Alternative entry thread sizes are also available.
For non-standard armour, alternative clamping rings are available.
See data sheet No. G23 for more information.
|
