Features
- 28-page Document Memory*¹*²
- Enhanced Copier Function
- Navigator Key for Easy Operation
- Quick Scan
- Sequential Broadcasting ( 20 locations )
- Error Correction Mode
- Informative 2-line LCD Screen
- Others Features
28-page Document Memory
The System can store up to 25 pages in its built-in memory for transmission. Ideal for broadcasting multi-page documents to multiple locations, and for receiving faxes when out of paper up to 28 pages.
Enhanced Copier Function
This fax provides you every copying feature you need, in one machine. The Enlarge (200%/150%), reduce (92%/86%/72%), collate (sort), make up to 50 copies. Furthermore this fax performs a range of advanced copier functions.
Navigator Key for Easy Operation
The navigator key lets you easily control the volume and ringer level, as well as the phone directory & dialer, and the other advanced functions.
Quick Scan
Speed less time waiting for your documents to scan! The features rapidly scans a document into memory & then sends the document from memory to the recipient.
Sequential Broadcasting ( 20 locations )
Broadcasting functions allow you to send multiple documents to mutilple locations in sequence. Up to 20 locations can be registered for destinations.
Error Correction Mode
The Systems's ECM checks documents line by line during transmission. If it detects caused by line noise, it resends the same line to ensure good quality.
Informative 2-line LCD Screen
The 2 x 16 character LCD readout indicates operating modes, memory contents, clock time, and telephone number dialed. Also it helps during programming system features or storing telephone number in directory.
Others Features
- Distinctive Ring detection*³
- 2-line LCD readout
- 64-level halftone resolution
- Polling function
- Friendly fax reception
- Extension line transfer
- 10-page Automatic document feeder
- 50-sheet paper tray
- 1-6 one-touch dialer
- Phonebook 100-station
- Electronic volume control
- Handset mute
- External telephone jack
Specification
Facsimile: |
|
Compatibility |
ITU-T G3 |
Paper Handling |
A4 |
Scanning width |
208mm |
Resolution |
Standard/fine/super fine/photo |
Halftone 64 levels |
Halftone 64 levels |
Modem speed |
9.6 kbps |
Transmission speed |
Approx. 12 sec/page*¹ |
Compression system |
MH, MR, MMR |
Document memory |
Max 28 pages*¹*² |
Print Method |
Thermal transfer for plain paper |
Ink Film |
70m (10m film included ) |
Paper Capacity |
Max 50 sheets (75g/m2 paper) |
Automatic Document Feeder Max |
10 sheets |
Integrated Telephone System : |
|
Dial Mode |
Tone (DTMF)/ Pulse |
Dialing Memory |
106 telephone numbers with name |
Power source |
AC220-240V, 50/60 Hz |
Resolution |
Standard/fine/super fine/photo |
Dimensions (HxWxD) |
18.5cm x 35.5cm x 27.2cm |
Accessories
Replacement inkfilm |
KX-FA57E (70m Ink Film roll) |
