- adjustable impulse current and impulse frequency
- Multi - purpose welder with lower cost
- Good flow over performance, precise control of current
- Be able to weld automatically, can equip with circle tank
- Equip with IGBT technology
Specification
| Input Power Voltage (V) | 415V ± 15% |
| Frequency (Hz) | 50/60 |
| Rated input power capacity (KVA) | 19 |
| No-Load Voltage (V) | 60V |
| Output current adjustment range (A) | TIG: 20 - 500 MMA: 20 - 450 |
| Output voltage (V) | 30 |
| Duty Cycle(%) (25 °C) | 60 |
| No-Load Consumption (W) | 100 |
| Power factor (COS ᶲ) | 0.93 |
| Effiency (%) | 85 |
| ARC force adjustment (A) | 0 - 130 |
| Measurement (mm) | 580 x 334 x 480 |
| Weight (KG) | 42 |
| Suitable Welding Thickness (mm) | 0.5 - 20 |
