- Small measurement, portable and multipurpose welder
- Easily arc - starting, stable current
- Beautiful welding seam
- Single - dial adjustable welding current allowing infinite current control
Specification
| Input Power Voltage (V) | 220V ± 15% |
| Frequency (Hz) | 50/60 |
| Rated input power capacity (KVA) | 4.5 |
| No-Load Voltage (V) | 56V |
| Output current adjustment range (A) | TIG: 10 - 200 MMA: 10 - 160 |
| Output voltage (V) | 18 |
| Duty Cycle(%) (25 °C) | 60 |
| Power factor (COS ᶲ) | 0.93 |
| Effiency (%) | 85 |
| ARC starting | HF |
| Current rise time | 0 - 9.9 |
| Current fall time | 0 - 9.9 |
| Pre-blow gas (s) | 0.1 - 9.9 |
| Post-blow gas (s) | 0.1 - 9.9 |
| Pulse frequency (Hz) | 1 - 200 |
| Measurement (mm) | 390 x 164 x 300 |
| Weight (KG) | 9.5 |
| Suitable Welding Thickness (mm) | 0.3 - 10 |
