- Narrow and smooth cut-edge
- Adopting no-contact arc starting cutting technique
- Adopting IGBT to realize the procession feedback controlling with stable output current
- Adjustable cutting current, apply for different material, thickness and cutting speed
- Automatic protective function of over - voltage, current & heating
Specification
| Input Power Voltage (V) | 415 ± 15% |
| Frequency (Hz) | 50/60 |
| Rated Input Power Capacity (KVA) | 30.0 |
| Output Current Adjustment Range (A) | 20 - 160 |
| Output Voltage (V) | 144 |
| Duty Cycle(%) (25 °C) | 60 |
| No-Load Consumption (W) | 150 |
| Power Factor (COS ᶲ) | 0.93 |
| Effiency (%) | 85 |
| Measurement (mm) | 670 x 335 x 633 |
| Weight (KG) | 57 |
| Exhaust (m/min) | 0.50 |
| Maximum Cutting Thickness (mm) | 50 |
| Quality cutting Thickness (mm) | 30 |
