- Integrated wire feeder and power
- User-friendly, high welding speed, high succeed rate of arc start
- Uninterrupted wire feeding
- Litte spark, deep welding poop, beautiful welding seam, heat-proof and split proof
- Adopting IGBT technology, stable output current
- 2 digital meters for reprenting or monitoring welding voltage and amperage
Specification
| Input Power Voltage (V) | 415v ± 15% |
| Frequency (Hz) | 50/60 |
| Rated Input Power Capacity (KVA) | 14 |
| Output Current Adjustment Range (A) | 50 - 350 |
| Output Voltage (V) | 39 |
| Duty Cycle(%) (25 °C) | 60 |
| Power Factor (COS ᶲ) | 0.93 |
| Effiency (%) | 85 |
| Feeding Speed (m/min) | 3.0 - 15 |
| Diameter of Coil (mm) | 270 |
| Post-Welding Gas Flow Time | 15 - 20 |
| Measurement (mm) | 545 x 280 x 495 |
| Weight (KG) | 58 |
| Suitable Welding Thickness (mm) |
≥ 1.0
|
| Diameter of Rod (mm) | 1.0 - 1.2 |
