- Integrated wire feeder and power
- User-friendly, high welding speed, high succeed rate of arc start
- Uninterrupted wire feeding
- Litte spark, deep welding poop, beautiful welding seam, heat-proof and split proof
Specification
| Input Power Voltage (V) | 415v ± 15% |
| Frequency (Hz) | 50/60 |
| Rated Input Power Capacity (KVA) | 8.3 |
| Output Current Adjustment Range (A) | 50 - 250 |
| Output Voltage (V) | 26.5 |
| Duty Cycle(%) (25 °C) | 60 |
| Power Factor (COS ᶲ) | 0.93 |
| Effiency (%) | 85 |
| Feeding Speed (m/min) | 2.5 - 13 |
| Diameter of Coil (mm) | 270 |
| Post-Welding Gas Flow Time | 1 ± 0.5 |
| Measurement (mm) | 610 x 300 x 580 |
| Weight (KG) | 38 |
| Suitable Welding Thickness (mm) |
≥ 0.8
|
| Diameter of Rod (mm) | 0.8 - 1.0 |
