Microweily High Speed Precision Lathe Machine -
16 Series
UMEQ is now selling Microweily High Speed Precision Lathe machine. All Microweily machine is being being manufactured from Taiwan and UMEQ is one of the distributor in Malaysia. The main features for these Taiwanese Lathe machine includes:-
- The slideways between the saddle and bed are TURCITE B coated
- Reducing the friction resistance
- Saving power consumption
- Handier operation
- The cross slide is induction hardened to HRC 52° and precision ground
- 2 speeds feed tailstock is standard supplied
- Hardened and precision ground gears and bedway.
Specification for Microweily High Speed Precision Lathe:-
| DE |
UNITS |
TY-1630S
|
TY-1640S
|
||
|
CAPACITY
& DIMENSIONS |
Swing over bed
|
mm (in) |
410 (16)
|
||
|
Swing over cross slide
|
mm (in) |
240 (9-7/16)
|
|||
|
Swing in gap
|
mm (in) |
595 (23-7/16)
|
|||
|
Length of gap in front of
face plate |
mm (in) |
155 (6-1/8)
|
|||
|
Center height
|
mm (in) |
205 (8-1/16)
|
|||
|
Distance between centers
|
mm (in) |
762 (30)
|
1016 (40)
|
||
|
Bed width
|
mm (in) |
300 (11-13/16)
|
|||
|
Bed length
|
mm (in) |
1646 (64 13/16)
|
1900 (74-3/4)
|
||
|
Bed height
|
mm (in) |
310 (12-7/32)
|
|||
|
Motor for main spindle
|
hp |
5HP 4P 3Ph / 7-1 / 2HP 4P 3Ph (Optional)
|
|||
|
Motor for coolant pump
|
hp |
1/8HP 2P 3Ph
|
|||
|
HEADSTOCK
|
Spindle bore
|
mm (in) |
52 (2-1/16)
|
||
|
Spindle nose
|
D1-6
|
||||
|
Spindle taper in nose / sleeve
|
No.6 / No.4 Morse
|
||||
|
Number of spindle speeds
|
12
|
||||
|
Speed range
|
rpm |
30-2000
|
|||
|
CARRIAGE
& COMPOUND |
Cross slide width / travel
|
mm (in) | 180 (7-3/32) / 230 (9) | ||
|
Compound rest width / travel
|
mm (in) | 110 (4-11/32) / 120 (4-3/4) | |||
|
Leadscrew diameter & thread
|
mm (in) | 32 (1-1/4) & 6mm pitch (4 T.P.I). | |||
|
THREADS
& FEEDS |
Imperial threads
|
40 Nos. 2-56 T.P.I.
|
|||
|
Metric threads
|
mm |
53 Nos. 0.4-14 Pitch
|
|||
|
Diametral pitch threads
|
32 Nos 4-32 D.P.
|
||||
|
Module pitch threads
|
44 Nos. 0.4-7 M.P.
|
||||
| Cross feeds |
Imperial
|
in/rev |
40 Nos. 0.0006-0.0126
|
||
| Metric | mm/rev | 40 Nos. 0.016-0.449 | |||
| Longitudinal feeds | Imperial | in/rev | 40 Nos. 0.0012-0.0252 | ||
| Metric | mm/rev | 40 Nos. 0.032-0.898 | |||
|
TAILSTOCK
|
Quill dia./ travel
|
mm (in) | 54 (2 1/8) / 120 (4 3/4) | ||
|
Quill taper
|
No.4 Morse
|
||||
|
WEIGHT
&
MEASURES (APPROX.) |
Machine length |
mm (in) |
1986 (78-3/16)
|
2240 (88-1/4)
|
|
| Machine width | mm (in) |
980 (38-5/8)
|
|||
| Machine height | mm (in) |
1205 (47-1/2)
|
|||
| Packing dimensions | in |
81x44x65
|
91x44x65
|
||
| Net weight | kg (lbs) |
1575 (3475)
|
1750 (3860)
|
||
| Gross weight | kg (lbs) |
1800 (3970)
|
2000 (4410)
|
||
