| MAGNUM |
| Description : |
The MAGNUM is a new high dump sweeper designed and manufactured to sweep medium to large floor areas.
The structure is particularly strong to allow the machine to perform in industrial areas, while particular attention has been given to the external finish to give a very aesthetic appearance.
• "MULTIBRISTLE" ® system on main brush.
• Floating, rapid replacement main brush.
• Main brush stops when hopper is raised.
• Side brush can be replaced quickly.
• Hopper floating system.
• Access door for hopper.
• "MULTIPHASE" ® exclusive filtering system.
• Drive on front wheels.
• Hydraulic drive on all versions.
• Adjustable pressure from operator's position on main and side brushes.
• Rapid replacement rubber flaps.
• Automatic vacuum cut-off.
• "EASY-START" ® device for immediate start.
• Non-marking tyres.
Comes in various models ranging from
MAGNUM BS - with petrol engine
MAGNUM G - with LPG drive
MAGNUM DR - with air cooled diesel engine
MAGNUM DK - with liquid cooled diesel engine
MAGNUM EB - with batteries
MAJOR SPECIFICATIONS
| Sweeping path with one side brush |
1250 mm |
| Cleaning capacity with one side brush |
12.500 mt/h |
| Main brush length |
902 mm |
| Hopper capacity (weight) |
220 kgs |
| Dumping height (multilevel) |
1.550 mm |
| Turning circle |
1725 mm |
| Type of filters (primary system) |
10 cartridges |
| Filtering area |
8.4 mt |
| Additional filtering system |
1 panel |
| Filter on air exhaust |
1 panel |
|
| |
|
|
 |
|
