Features
- Bigger 7 Segment, 7 Digit Blue Color Display.
- Auto Span Calibration.
- Shielded by Aluminium Housing for Immunity Against All forms of Radio Frequency Interference and Susceptibility.
- Wide Range of Capacity and Division can be easily set by Keypad.
- Push Button Tare or Auto Tare Function.
- Peak-Hold and Sample-Hold Function.
- M+M-(Automatic Accumulated Date Store)
Specification
1. Analog Input & A/D Conversion Section
| Input Sensitivity | 0.2 μ V/D |
|---|---|
| Zero Adjust Range | -4 mV ~ 42.0 mV |
| Load cell Supply Voltage | DC 10V( ± 5V) |
| Max. loadcell Input Voltage | 32 mV |
| Temperature Coefficient | ± 20 ppm / °C |
| Input Noise | ± 0.5 μv P.P |
| Input Impedance | More than 10 ΜΩ |
| A/D Conversion | 130,000 Count |
| Non-Linearty Range | 0.005% of Full Scale |
| Conversion Method | Dual – Slop |
2. Digital Section
| Max. Display | “1000000” |
|---|---|
| A Digit | x1, x2, x5, x10, x20, x50 |
| Display | 7 Segment, 7Digit Highly Bright Fluorescent Tube |
| Character Size | 10mm Height |
| Keypad | Numeral Keypad and Function Key(0~9),CLR,SET,PRINT |
| Data Back-Up | Permanent Record |
3. General Section
| Power Voltage | VAC 110 / 220V(± 10%), 50/60Hz |
|---|---|
| Indicator Weight | Net 3.3Kg, Packing 3.8Kg |
| Temperature | -10 °C ~ 40°C |
| Moisture | Less than 85% RH |
| Dimension | 193.6mm x 98mm x 160mm |
4. Option Section
| Basic Standard 1 | Serial Interface : RS-232C |
|---|---|
| Option 2 | Current Loop |
| Option 3 | Parallel Interface : BCD OUT Weight( Positive, Negative Logic) |
| Option 4 | Serial Interface : RS-422, RS-485 |
| Option 5 | Analog Output : 0~10V or 10V ~ 0V |
| Option 6 | Analog Output : 4~20 mA or 20 ~ 4 mA |
| Option 7 | Printer Interface : Centronics Parallel |
| Option 10 | Parallel Interface : BCD In PART |
Cutting Size
