| SPECIFICATION |
| Max. working thickness |
100mm |
| Working length |
100mm and over |
| Feed Chaintrack |
| Motor horse power |
3(5)hp |
| Feed speed |
5-25m/min |
| Distance between dogs |
400(300/200)mm or without dogs |
| Moulding Unit 1 (equipped with jumping function) |
| Motor horse power |
7.5(10)hp |
| Spindle speed |
3000-6000(10000)rpm |
| Spindle diameter |
40mm |
| Cutter diameter |
190-250mm |
| Moulding Unit 2 |
| Motor horse power |
7.5(10)hp |
| Spindle speed |
3000-6000(10000)rpm |
| Spindle diameter |
40mm |
| Cutter diameter |
190-250mm |
| Profile Sanding Unit |
| Motor horse power |
3hp x 3pcs |
| Spindle speed |
0-1800rpm |
| Weight |
| N.W. |
4250kg |
| G.W. |
4600kg |
| Dimensions |
| Machine size |
4110x1620x1900mm |
| Packing size |
4230x1600x2120mm |
|
